Nissan Altima L30 (1997-1999) pass pass low low hi hi Wiring diagram
This page shows the only wiring diagram for the component.pass pass low low hi hi, which is found in the car Nissan Altima L30 (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass pass low low hi hi (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER HI BEAM IND
DIODE (LEFT SIDE OF DASH)
ECCS CONTROL MODULE (ECM) (BEHIND DASH LOWER COVER)
FRONT FOG LAMP RELAY (IN RELAY BOX 1, RIGHT SIDE OF ENGINE COMPT)
FRONT FOG LAMP SWITCH
FUSE 32
FUSE 33
FUSE 43
FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LIGHTING SWITCH
OFF
ORG/ WIRE
PASS LOW HI
PASS PASS LOW LOW HI HI
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
THEFT WARNING LAMP RELAY (IN RELAY BOX, RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, without drl -> PASS PASS LOW LOW HI HI
