Nissan Altima L30 (1997-1999) limit switch 2 tilt sw slide sw Wiring diagram
This page shows the only wiring diagram for the component.limit switch 2 tilt sw slide sw, which is found in the car Nissan Altima L30 (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram limit switch 2 tilt sw slide sw (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CIRCUIT BREAKER 1 (BEHIND LEFT SIDE OF DASH)
DOOR LOCKS SYSTEM
DOWN/OPEN RELAY
FULL CLOSED
FULL OPEN
FULL TILT DOWN
FULL TILT UP
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START FUSE BLOCK (UNDER LEFT SIDE OF DASH) FUSE 8
LIMIT SWITCH 1 TILT SW
LIMIT SWITCH 2 TILT SW SLIDE SW
NCA WIRE
POWER WINDOW RELAY (BEHIND LEFT SIDE OF DASH)
POWER WINDOWS SYSTEM
RED WIRE
SLIDE OPEN/ TILT DOWN SLIDE CLOSE/ TILT UP
SLIDE SW
SUN ROOF MOTOR ASSEMBLY (AT FRONT OF SUN ROOF OPENING)
SUN ROOF SWITCH
UP/CLOSE RELAY
WHT/BLU WIRE
Go to component -> Power top/sunroof circuits -> LIMIT SWITCH 2 TILT SW SLIDE SW
