Nissan Altima L30 (1997-1999) left tweeter Wiring diagram
This page shows the only wiring diagram for the component.left tweeter, which is found in the car Nissan Altima L30 (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left tweeter (1 of 1)
1996 VFTC
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
FUSE 10
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT) FUSE 35
HOT AT ALL TIMES
HOT IN ON OR ACC
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LEFT TWEETER
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER ANTENNA ANTENNA IN
POWER ANTENNA SYSTEM
RADIO, CASSETTE, CD PLAYER
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
RIGHT TWEETER
RR LH (-) AMP RR LH (+) AMP RR RH (-) AMP RR RH (+) AMP
WINDOW ANTENNA ANTENNA IN
Go to component -> Premium sound radio circuit -> LEFT TWEETER
