Nissan Altima L30 (1997-1999) left rear door switch right front door switch Wiring diagram
This page shows the only wiring diagram for the component.left rear door switch right front door switch, which is found in the car Nissan Altima L30 (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear door switch right front door switch (1 of 1)
BATTERY
BLK WIRE
BLU WIRE
CIRCUIT BREAKER 1 (BEHIND LEFT SIDE OF DASH)
DIODE (LEFT SIDE OF TRUNK)
DOOR
FUSE
FUSE 24
FUSE 8
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
FUSIBLE LINK, FUSE BOX (LEFT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRN/RED WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION
KEY SW
KEY SWITCH
LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR SWITCH RIGHT FRONT DOOR SWITCH
LEFT VANITY MIRROR ILLUMINATION
LF DOOR SW
LF LOCK SW
OFF ON
PNK WIRE
REAR DOOR SW
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RF DOOR SW
RIGHT REAR DOOR SWITCH
RIGHT VANITY MIRROR ILLUMINATION
ROOM LAMP
SMART ENTRANCE CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN)
SPOT LAMP
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH
W/ ANTI- THEFT
W/O ANTI- THEFT
WHT WIRE
WHT/BLU WIRE
Go to component -> Courtesy lamps circuit, with door locks -> LEFT REAR DOOR SWITCH RIGHT FRONT DOOR SWITCH
