Nissan Altima L30 (1997-1999) key sw key cyl sw key cyl sw r door sw Wiring diagram

1 2 3 BAT UNLOCK OUTPUT UNLOCK OUTPUT LOCK OUTPUT BLK WIRE BLU WIRE BLU/ORG WIRE CIRCUIT BREAKER 1 (BEHIND LEFT SIDE OF DASH) FULL STROKE LOCK FULL STROKE UNLOCK FUSE 24 FUSE 8 FUSE BLOCK (UNDER LEFT SIDE OF DASH) GRN WIRE GRN/RED WIRE GRN/YEL WIRE GROUND IGN UNLOCK SENSE UNLOCK SENSE UNLOCK SENSE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START KEY SW KEY CYL SW KEY CYL SW R DOOR SW KEY SWITCH L DOOR SW LOCK UNLOCK PPL LEFT "C" PILLAR) LEFT DOOR KEY CYLINDER SWITCH LEFT FRONT DOOR LOCK ACTUATOR LEFT FRONT DOOR SWITCH LEFT REAR DOOR LOCK ACTUATOR LOCK LT GRN WIRE LT GRN/RED WIRE MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH MID STROKE MULTI- REMOTE SYSTEM PNK WIRE PPL RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT DOOR KEY CYLINDER SWITCH RIGHT FRONT DOOR LOCK ACTUATOR RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR LOCK ACTUATOR SMART ENTRANCE CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN) UNLOCK W/O MULTI- REMOTE SYSTEM WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
