Nissan Altima L30 (1997-1999) grn blk/ Wiring diagram
This page shows the only wiring diagram for the component.grn blk/, which is found in the car Nissan Altima L30 (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram grn blk/ (1 of 1)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
CONDENSER (ON LEFT "C" PILLAR)
FUSE 4
FUSE 8
FUSE BLOCK (J/B) FUSE 5
GRN BLK/ WIRE
GRN RED/ WIRE
GRN WIRE
GRN/ WHT WIRE
GRN/BLK WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILLUM
IND
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY (BEHIND LEFT SIDE OF DASH, ATTACHED TO FUSE BLOCK)
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
WHT WIRE
Go to component -> Defogger circuit -> GRN BLK/ WIRE
