Nissan Altima L30 (1997-1999) fuse and fusible link box fuse 36 Wiring diagram
This page shows the only wiring diagram for the component.fuse and fusible link box fuse 36, which is found in the car Nissan Altima L30 (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse and fusible link box fuse 36 (1 of 1)
1994 VFTC
A/C COMPRESSOR
ACRLY
AIR CONDITIONER
AMBIENT TEMPERATURE SWITCH (BEHIND CENTER OF FRONT BUMPER)
BLK WIRE
BRN WIRE
COOLING FAN MOTOR 1
COOLING FAN MOTOR 2
COOLING FAN RELAY 1 (RIGHT FRONT OF ENGINE COMPT)
COOLING FAN RELAY 2
COOLING FAN RELAY 3
DIODE (BEHIND LEFT SIDE OF DASH)
ENGINE CONTROL MODULE (BEHIND CENTER OF DASH)
FUSE 39
FUSE AND FUSIBLE LINK BOX FUSE 36
FUSIBLE LINK B
FUSIBLE LINK C
FUSIBLE LINK E
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON AND START FUSE BLOCK FUSE 25
IACV-FICD SOLENOID VALVE (RIGHT REAR OF ENGINE)
LEFT FRONT FENDER)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
NCA WIRE
RED/YEL WIRE
RELAY (RIGHT FRONT OF ENGINE COMPT)
RFRH
RFRL
TASW
THERMAL PROTECTOR (RIGHT SIDE OF ENGINE COMPT)
WHT/BLU WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> A/c circuit (2 of 2) -> FUSE AND FUSIBLE LINK BOX FUSE 36
