Nissan Altima L30 (1997-1999) fuse 22 fuse 21 fuse 17 Wiring diagram
This page shows the only wiring diagram for the component.fuse 22 fuse 21 fuse 17, which is found in the car Nissan Altima L30 (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 22 fuse 21 fuse 17 (1 of 1)
ACCESSORY RELAY
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM, BODY COMPUTER SYSTEM
BLK WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM AIR CONDITIONING SYSTEM
FROM BLOWER RELAY (DIAGRAM 2 OF 2)
FROM FUSE A (DIAGRAM 1 OF 2)
FROM FUSE G (DIAGRAM 1 OF 2)
FUSE 1
FUSE 10
FUSE 11 FUSE 12 FUSE 18
FUSE 13 FUSE 9
FUSE 19
FUSE 2
FUSE 22 FUSE 21 FUSE 17
FUSE 25
FUSE 26
FUSE 28
FUSE 3
FUSE 6
FUSE 7
FUSE 8
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRY WIRE
IGNITION RELAY
IGNITION SWITCH
OFF
ORG/ WIRE
PNK WIRE
POWER MIRRORS SYSTEM
PPL
RED WIRE
SOUND SYSTEMS
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TO IGNITION RELAY (DIAGRAM 2 OF 2)
TRANSMISSION SYSTEM
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> FUSE 22 FUSE 21 FUSE 17
