Nissan Altima L30 (1997-1999) express down circuit Wiring diagram
This page shows the only wiring diagram for the component.express down circuit, which is found in the car Nissan Altima L30 (1997-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram express down circuit (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
CIRCUIT BREAKER 1 (BEHIND LEFT SIDE OF DASH)
DN UP
DN UP DN UP
DOOR LOCKS SYSTEM
EXPRESS DOWN CIRCUIT
FRONT LEFT -
FUSE 8
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR POWER WINDOW MOTOR DN
LEFT REAR POWER WINDOW SWITCH
LOCK
MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH
NCA WIRE
POWER TOPS SYSTEM
POWER WINDOW RELAY (BEHIND LEFT SIDE OF DASH)
RED WIRE
RIGHT FRONT POWER WINDOW MOTOR DN
RIGHT FRONT POWER WINDOW SWITCH
RIGHT REAR POWER WINDOW MOTOR DN
RIGHT REAR POWER WINDOW SWITCH DN UP
UNLOCK
UP DN
UP LEFT REAR SW
UP RIGHT FRONT SW LOCK SW
UP RIGHT REAR SW
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power window circuit -> EXPRESS DOWN CIRCUIT
