Nissan 370Z I facelift (2012-2020) p/w, soft top c/u comm Wiring diagram
This page shows the only wiring diagram for the component.p/w, soft top c/u comm, which is found in the car Nissan 370Z I facelift (2012-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram p/w, soft top c/u comm (1 of 1)
ACTUATOR
BATT (F/L)
BATT FUSE
BCM (BODY CONTROL MODULE) (LOWER RIGHT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
FUSE 10
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK K
GRY WIRE
HOT AT ALL TIMES
LOCAL COMM
LT GRN WIRE
ORG/ WIRE
P/W, SOFT TOP C/U COMM
PNK WIRE
PPL
RIGHT END OF DASH)
SOFT TOP CONTROL UNIT
TAN WIRE
TRUNK LID DOOR REQUEST SWITCH
TRUNK LID DOOR REQUIRED SW
TRUNK LID LOCK ASSEMBLY
TRUNK LID OPEN SK
TRUNK LID OPENER ACTUATOR
TRUNK LID OPENER CANCEL SW
TRUNK LID OPENER CANCEL SWITCH
TRUNK LID OPENER OUT
TRUNK LID OPENER SW
TRUNK LID OPENER SWITCH
TRUNK LID OPENER SWITCH ASSEMBLY
TRUNK OPENER
TRUNK ROOM LAMP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Trunk release circuit, roadster -> P/W, SOFT TOP C/U COMM
