Nissan 370Z I (2008-2014) str rly cont clutch interlock sw shift p/n Wiring diagram
This page shows the only wiring diagram for the component.str rly cont clutch interlock sw shift p/n, which is found in the car Nissan 370Z I (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram str rly cont clutch interlock sw shift p/n (1 of 1)
A/T
A/T ASSEMBLY
BATTERY
BATTERY TERMINAL W/ FUSIBLE LINK
BCM (BODY CONTROL MODULE) (BEHIND LEFT
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CLUTCH INTERLOCK SWITCH (ON CLUTCH PEDAL BRACKET)
COMPUTER DATA LINES SYSTEM
COUPE MODELS
FUSE 51 FUSE 50
FUSE 9
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK, RELAY BOX (RIGHT REAR SIDE OF ENGINE COMPT)
FUSIBLE LINK G
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
KICK PANEL)
LT BLU WIRE
M/T
OUTPUT SPEED SENSOR
PNK WIRE
PPL
PUSH SW
PUSH SWITCH PUSH BUTTON IGNITION SWITCH
RED WIRE
ROADSTAR MODELS
STARTER CONTROL RELAY
STARTER MOTOR
STARTER RELAY
STR RLY CONT CLUTCH INTERLOCK SW SHIFT P/N
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION RANGE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Starting circuit -> STR RLY CONT CLUTCH INTERLOCK SW SHIFT P/N
