Nissan 370Z I (2008-2014) shield shield sound sig tel + sound sig tel - tel on Wiring diagram
This page shows the only wiring diagram for the component.shield shield sound sig tel + sound sig tel - tel on, which is found in the car Nissan 370Z I (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shield shield sound sig tel + sound sig tel - tel on (1 of 1)
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 PPL
16 17 18 19 PPL
2 1 AM-FM MAIN ANT AMP ON SIG
21 22 23 24 25 26 27 28 29 30 AV COMM H AV COMM L
3 5 15 16 PPL
34 33 SHIELD SATELLITE ANTENNA SIG
6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 STRG SW A
ANTENNA AMP ON SIG ANTENNA SIG 43 44
ANTENNA AMPLIFIER
AUDIO UNIT
BASE ANTENNA
BATTERY
BATTERY SHIELD SHIELD
BLK WIRE
BLU WIRE
BOSE AMPLIFIER (LEFT REAR OF
BRN WIRE
COMM SIG (AUDIO SAT) COMM SIG (SAT AUDIO) REQUEST SIG (SAT AUDIO)
COUPE ROADSTER
GLASS ANTENNA
GRN WIRE
GRY WIRE
HOT IN ACC OR ON FUSE BLOCK (J/B) FUSE 19 (BEHIND LEFT KICK PANEL)
LEFT "C" PILLAR)
LEFT FRONT DOOR SPEAKER
LEFT REAR SPEAKER
LEFT RIGHT FRONT TWEETER DOOR SPEAKER (ROADSTER)
LR SPKR SIG (-)
LT BLU WIRE
LT GRN WIRE
LUGGAGE ROOM)
NCA WIRE
ORG/ WIRE
PNK (OR YEL) WIRE
PNK LR SPKR SIG- RH SIG TWEETER - WIRE
PNK WIRE
PPL
RED WIRE
REQUEST SIG (SAT AUDIO) COMM (SAT AUDIO) COMM (AUDIO SAT) PNK WIRE
RIGHT REAR SPEAKER
ROD ANTENNA
RR SOUND SIG - LF SOUND SIG - AMPLIFIER ON SIG
SATELLITE ANTENNA
SATELLITE RADIO ANTENNA
SATELLITE RADIO TUNER (LEFT REAR OF VEHICLE)
SHIELD
SHIELD 56 54 55
SHIELD SHIELD
SHIELD SHIELD SHIELD 68 69 70 63 64 62
SHIELD SHIELD SOUND SIG TEL + SOUND SIG TEL - TEL ON
SHILELD
TAN WIRE
WHT WIRE
WHT/ BLU WIRE
WOFR SIG +
WOOFER
YEL WIRE
Go to component -> Radio circuit, bose without navigation (1 of 2) -> SHIELD SHIELD SOUND SIG TEL + SOUND SIG TEL - TEL ON
