Nissan 370Z I (2008-2014) right storage lid status sensor Wiring diagram
This page shows the only wiring diagram for the component.right storage lid status sensor, which is found in the car Nissan 370Z I (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right storage lid status sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DEFOGGER SYSTEM
DK GRN WIRE
DRIVER SIDE DOOR REQUEST SWITCH
GRN WIRE
LATCH CLOSE SENSOR
LATCH OPEN SENSOR
LEFT ROOF STATUS SENSOR
LEFT ROOF STATUS SENSOR (CLOSE)
LEFT ROOF STATUS SENSOR (OPEN)
LEFT STORAGE LID STATUS SENSOR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER SIDE DOOR REQUEST SWITCH
PNK PPL WIRE
PNK WIRE
PPL
PTC - SENSOR GND 4 SENSOR GND 3 SENSOR GND 2
REAR WINDOW DEF OUT 1
RED WIRE
RED/BLK WIRE
RIGHT END OF DASH)
RIGHT ROOF STATUS SENSOR
RIGHT STORAGE LID STATUS SENSOR
ROOF LATCH LOCK SENSOR
SOFT TOP CONTROL UNIT (FRONT UPPER CENTER OF REAR COMPT)
STATUS SENSOR
STRIKER SENSOR
TAN WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit (3 of 3) -> RIGHT STORAGE LID STATUS SENSOR
