Nissan 370Z I (2008-2014) left roof striker sensor Wiring diagram
This page shows the only wiring diagram for the component.left roof striker sensor, which is found in the car Nissan 370Z I (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left roof striker sensor (1 of 1)
17 16 PPL
41 42 43 44 45 46 47 48 49 50 51 52 TRUNK OPENER ACTUATOR
53 54 55 BATTERY GND
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CLOSE
COMBINATION METER (SOFT TOP)
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DK GRN WIRE
FUSE 33
FUSE, FUSIBLE LINK, RELAY BOX (RIGHT REAR SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT ROOF STRIKER SENSOR
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPT)
MODULE
OPEN ROOF OPEN/ CLOSE SWITCH
ORG/ WIRE
PNK ROOF OPEN/CLOSE SW WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH
PPL
PPL 25 24 15
RED WIRE
RH ROOF STRIKER SENS LH ROOF STRIKER SENS
RIGHT ROOF STRIKER SENSOR
RR WIND DEFOG IN 2 RR WIND DEFOG IN 1
SOFT TOP CONTROL UNIT (FRONT UPPER CENTER OF REAR COMPT)
STATUS SIG ROOF
TAN WIRE
TRUNK LID LOCK ASSEMBLY
TRUNK LID OPENER ACTUATOR
TRUNK ROOM LAMP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit (1 of 3) -> LEFT ROOF STRIKER SENSOR
