Nissan 370Z I (2008-2014) acc pwr supply intake sens sig sens sig Wiring diagram
This page shows the only wiring diagram for the component.acc pwr supply intake sens sig sens sig, which is found in the car Nissan 370Z I (2008-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram acc pwr supply intake sens sig sens sig (1 of 1)
2 3 1 4 5 6 ILL+ ILL- PWR SUPPLY TX RX GND
6 4 PWR SUPPLY LAN SIG
A/C AUTO AMP
A/C AUTO AMPLIFIER
A/C CONTROL (W/O NAVIGATION)
ACC PWR SUPPLY INTAKE SENS SIG SENS SIG
AIR MIX DOOR MOTOR (BEHIND CENTER OF DASH)
AMBIENT SENS GND
AMBIENT SENS SIG
AMBIENT SENSOR (FRONT OF ENGINE COMPT, BEHIND GRILLE)
AMP
BATTERY TERMINAL W/ FUSIBLE LINK
BLK WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
COMBINATION METER
DEFOG FEED BACK SIG DEFOG ON SIG
DEFOGGER SYSTEM
ECV SIG
FUSE 19
FUSE 21 FUSE 22
FUSE 3
FUSE 6
FUSIBLE LINK E
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR ACC FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
HOT IN ON OR START
IGN PWR SUPPLY GND
IN-VEHICLE SENSOR (BEHIND LEFT CENTER OF DASH)
INTAKE DOOR MOTOR (BEHIND RIGHT SIDE OF DASH)
INTAKE SENSOR (BEHIND RIGHT CENTER OF DASH)
LT GRN WIRE
MODE DOOR MOTOR (BEHIND CENTER OF DASH)
ORG/ WIRE
PNK BLWR MTR CTRL SIG WIRE
PNK COMPUTER CAN-L CAN-H DATA LINES SYSTEM WIRE
PNK RX (CONT) TX (AMP) WIRE
PNK WIRE
PPL
RED WIRE
RIGHT END OF DASH)
SENS GND VEH SENS SIG SENS SIG A/C AUTO AMP
SUNLOAD SENSOR (TOP LEFT SIDE OF DASH) (LEFT END OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 2) -> ACC PWR SUPPLY INTAKE SENS SIG SENS SIG
