Nissan 370Z I (2008-2014) 4 2 microphone vcc shield shield Wiring diagrams
This page contains all the electrical diagrams for the component. 4 2 microphone vcc shield shield, in which he is found in the car Nissan 370Z I (2008-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 4 2 microphone vcc shield shield (1 of 2)
15 14 8 7 SHIELD
15 16 17 18 19 20 SHIELD
4 2 MICROPHONE VCC SHIELD SHIELD
A/T
A/T ASSEMBLY
A/T M/T
AV COMM (H)
AV COMM (L)
AV CONTROL UNIT
BACK TEL
BACKUP LIGHT RELAY
BACKUP LIGHT SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMBINATION SWITCH (SPIRAL CABLE)
COMM
COMPOSITE IMAGE GND
COMPOSITE IMAGE SIGNAL
COMPUTER DATA LINES SYSTEM
COUPE
FUSE 4 (BEHIND LEFT KICK PANEL)
FUSE BLOCK (J/B)
GRN WIRE
HOT IN ON OR START
IGNITION SIGNAL
JOINT CONNECTOR
LEFT FRONT DOOR SPEAKER
LT BLU WIRE
LT GRN WIRE
M/T
MENU MENU UP
MICROPHONE
MICROPHONE GND
MICROPHONE SIG
MICROPHONE SIGNAL
MICROPHONE VCC
NCA WIRE
ORG OR LT GRN WIRE
ORG/ WIRE
PARKING BRAKE SIGNAL
PARKING BRAKE SWITCH (ON PARKING BRAKE PEDAL BRACKET)
PNK PPL 1 2 3 4 5 6 7 8 9 WIRE
PNK WIRE
PPL
PPL 1 2 3 4 5 6 7 8
RED WIRE
REV LAMP RLY
REVERSE SIGNAL
RIGHT FRONT DOOR SPEAKER
ROADSTER
SHIELD
SOURCE
STEERING SWITCH
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
VEHICLE SPEED SIGNAL
VOLUME VOLUME ENTER VOICE DOWN UP DOWN
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit (2 of 4) -> 4 2 MICROPHONE VCC SHIELD SHIELD
