Car Wiring Diagrams for Charging circuit for Nissan 350Z I facelift (2005-2009)

ALTERNATOR BATTERY BLK WIRE BLK/YEL WIRE CHARGE INDICATOR COMBINATION METER ENGINE COMPT) FUSE FUSE 36 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK HOLDER FUSIBLE LINK A (RIGHT REAR SIDE OF ENGINE COMPT) GRN/RED WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LT GRN WIRE NCA WIRE STARTING CIRCUIT WHT/RED WIRE
