Car Wiring Diagrams for Electronic power steering circuit for Nissan 350Z I facelift (2005-2009)

1 2 3 4 5 6 7 8 9 10 11 12 SOL GND VIGN BLK WIRE BLK/RED WIRE BLU WIRE CAN L CAN-H COMPUTER DATA LINES OF DASH) SYSTEM ECM (ENGINE CONTROL MODULE) (BEHIND RIGHT END OF DASH) FUSE GRN WIRE GRN/BLK WIRE HOT IN ON OR START LT GRN WIRE PNK WIRE POWER STEERING CONTROL UNIT (BELOW LEFT SIDE OF DASH) POWER STEERING SOLENOID VALVE (LEFT SIDE OF ENGINE COMPT) RED WIRE SOL GND GND TACHO TECHO UNIFIED METER, A/C AMPLIFIER (UNDER CENTER OF DASH) VSP YEL WIRE
