Car Wiring Diagrams for Defoggers circuit for Nissan 350Z I facelift (2005-2009)

21 22 29 30 BATT IGN (POWER) GND GND 38 56 RR/DEF ON RR/DEF F/B 48 49 60 CAN-H CAN-L GND (SIGNAL) PNK WIRE 55 52 BAT(F/L) GND 72 78 84 87 VBL RR/DEF LED PUSH SW SW SEL 3 A/C CONTROLLER BLK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL) COUPE DRIVER SIDE DOOR MIRROR DEFOGGER FUSE 1 FUSE 12 FUSE 19 FUSE 6 FUSE 71 FUSE 78 FUSE 8 FUSE 80 FUSE 75 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSIBLE LINK F GND POWER GRN WIRE GRN/RED WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE, FUSIBLE LINK, RELAY BOX (RIGHT REAR SIDE OF ENGINE COMPT) HOT IN ON OR ACC HOT IN ON OR START IGN RR DEF SW CAN-H CAN-L LT GRN WIRE NCA WIRE PASSENGER SIDE DOOR MIRROR DEFOGGER PNK COMPUTER DATA LINES SYSTEM WIRE PNK WIRE PNK/BLU WIRE REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER RELAY (RIGHT REAR OF PASSENGER COMPT) RED WIRE RED/WHT WIRE ROADSTER RR DEF RLY SW SEL 3 PUSH SW RR/DEF LED VBL UNIFIED METER, A/C AMPLIFIER (UNDER CENTER OF DASH) WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE
