Nissan 350Z I facelift (2005-2009) seat back position output Wiring diagram
This page shows the only wiring diagram for the component.seat back position output, which is found in the car Nissan 350Z I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat back position output (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY INTERFERENCE PREVENTION SWITCH
CLOSE
DIODE (ROADSTER: NEAR BASE OF LEFT "B" PILLAR)
ENDING SWITCH
FULL CLOSE FULL CLOSE
FULL LATCH SW
FULL LATCH SWITCH
FULL OPEN OTHER
FULL OPEN SWITCH FULL OPEN
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HALF LATCH SWITCH
ILLUMINATION
LT GRN WIRE
OFF ON
ON OFF
ORG/ WIRE
OTHER
P/W DOWN REQUEST MONITOR
PASSENGER SEAT CONTROL UNIT
PASSENGER-SIDE SEAT
PNK WIRE
POWER WINDOW MAIN SWITCH SOFT TOP
POWER WINDOW SUB- SWITCH SOFT TOP
PPL
PPL/WHT WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR PLATE RAIL
ROLL BAR INTERFERENCE PREVENTION SWITCH
ROOF FULL CLOSE SWITCH
ROOF FULL OPEN SWITCH
S/LID CLOSE OUTPUT MONITOR
SEAT BACK POSITION OUTPUT
SOFT TOP LOCK SWITCH (CENTER OF REAR COMPT LID)
SOFT TOP SW (CLOSE)
SOFT TOP SW (OPEN)
SOFT TOP SWITCH
SOFT TOP SWITCH ASSEMBLY 1
SOFT TOP SWITCH ASSEMBLY 2 FULL CLOSED
SWITCH
UNLOCK ACTUATOR (LEFT SIDE OF REAR COMPT LID)
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Power top/sunroof circuit (2 of 2) -> SEAT BACK POSITION OUTPUT
