Nissan 350Z I facelift (2005-2009) fuse 76 fuse 86 fuse 74 cpu h/lp hi wiring diagram
This page shows the only wiring diagram for the component.fuse 76 fuse 86 fuse 74 cpu h/lp hi, which is found in the car Nissan 350Z I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
fuse 76 fuse 86 fuse 74 cpu h/lp hi wiring diagram (1 of 1)
A/C RELAY
A/T
AIR COMP
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEM
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES, ENGINE CONTROLS, TRANSMISSIONS, STARTING/CHARGING SYSTEMS
COMPUTER FROM FUSE DATA LINES BLOCK (J/B) SYSTEM (FUSE 12) (DIAGRAM 2 OF 3)
DEFOGGER RELAY
DEFOGGER SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, TRANSMISSIONS, NAVIGATION, EXTERIOR LIGHTS SYSTEMS
EXTERIOR LIGHTS, INTERIOR LIGHTS SYSTEMS
F/WIP RR +IG F/WIP DEF HI RLY RLY RLY
FROM FUSIBLE LINK HOLDER (FUSE C) (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FROM IPDM E/R
FROM IPDM E/R (FUSE 73) (DIAGRAM 3 OF 3)
FROM IPDM E/R (FUSE 77) (DIAGRAM 1 OF 3)
FRONT WIPER HIGH RELAY
FRONT WIPER RELAY
FUEL PUMP RELAY
FUSE
FUSE 71
FUSE 72
FUSE 75
FUSE 76 FUSE 86 FUSE 74 CPU H/LP HI
FUSE 79
FUSE 8
FUSE 83
FUSE 84 FUSE 81
FUSE 85 FUSE 82
FUSE 87
FUSE 89
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN RED/ WIRE
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
H/LP CAN- CAN- LO
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HEADLIGHTS SYSTEM
IGNITION RELAY
ORG/ WIRE
PNK WIRE
REAR WINDOW
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
TAIL LAMP RELAY
TAIL- +B LMP RLY
THROTTLE CONTROL MOTOR RELAY
TO IPDM E/R (FRONT WIPER RELAY) (DIAGRAM 3 OF 3)
WHT WIRE
WHT/BLU WIRE
WIPER/ ENGINE WASHER CONTROLS SYSTEM SYSTEM
WIPER/WASHER SYSTEM
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (3 of 3) -> FUSE 76 FUSE 86 FUSE 74 CPU H/LP HI
