Nissan 350Z I facelift (2005-2009) fuse 33 side of engine compt) Wiring diagram
This page shows the only wiring diagram for the component.fuse 33 side of engine compt), which is found in the car Nissan 350Z I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 33 side of engine compt) (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
DAYTIME LIGHT RELAY (CANADA) (IN RELAY BOX)
FUSE 33 SIDE OF ENGINE COMPT)
FUSE, FUSIBLE LINK BLOCK (RIGHT REAR
HEADLAMP HIGH, LOW
HID CONT
HIGH BEAM SOLENOID
HOT AT ALL TIMES
LEFT FRONT COMBINATION LAMP
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT COMBINATION LAMP
YEL WIRE
Go to component -> Headlights circuit, with drl (2 of 2) -> FUSE 33 SIDE OF ENGINE COMPT)
