Nissan 350Z I facelift (2005-2009) comp on sig fan on sig hazard sw interior trunk sw back dr opener sw Wiring diagram

41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 BAT SAVER OUT BAT (FUSE) AIR CONDITIONING SYSTEM ANTI-THEFT SYSTEM BLK WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL) BRN WIRE BRN/WHT WIRE COMP ON SIG FAN ON SIG HAZARD SW INTERIOR TRUNK SW BACK DR OPENER SW COMPUTER DATA LINES SYSTEM COUPE DEFOGGER SYSTEM DEFOGGER, ANTI-THEFT SYSTEMS DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS, TRUNK, TAILGATE, FUEL DOORS SYSTEMS DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, INTERIOR LIGHTS SYSTEMS DOOR LOCKS, INTERIOR LIGHTS, ANTI-THEFT SYSTEMS DOOR SW (DR) DR UNLOCK OUT (DR) FLASHER OUT (LEFT) FLASHER OUT (RIGHT) EXTERIOR LIGHTS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM FUEL LID OPENER REAR WIP MOTOR OUT FUSE FUSE, FUSIBLE LINK, RELAY BOX (RIGHT REAR SIDE OF ENGINE COMPARTMENT) FUSIBLE LINK F GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HEADLIGHTS, WIPER/WASHER, WARNING SYSTEMS HOT AT ALL TIMES HOT IN ON OR ACC FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE HOT IN ON OR START KEY SWITCH LT BLU WIRE LT GRN WIRE LUGGAGE LAMP OUT ORG/ WIRE PNK DOOR SW (AS) WIRE PNK ROOM LAMP OUT WIRE PNK WIRE POWER WINDOWS SYSTEM POWER WINDOWS, SEATS SYSTEMS POWER WINDOWS, DOOR LOCKS, ANTI-THEFT SYSTEMS PPL PPL DR LOCK OUT (ALL) DR UNLOCK OUT (AS) GND PPL/WHT WIRE PWR SERIAL LINK (IGN) SECURITY IND OUT PWR SPLY (BAT) BAT (F/L) PWR SPLY (RAP) RED WIRE RED/BLK WIRE RED/WHT WIRE ROADSTER RR DEF SW SENSOR GND KEYLS TUNER PWR SPLY KEYLESS TUNER SIG TPMS MODE TRIG SW TRUNK OPENER (OR) BACK DR OPENER OUT TRUNK SW BACK DOOR SW R WIPER AUTO STOP TRUNK, TAILGATE, FUEL DOORS SYSTEMS WARNING SYSTEM WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WIPER/WASHER SYSTEM WIPER/WASHER, TRUNK, TAILGATE, FUEL DOORS SYSTEMS YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE
