Nissan 350Z I facelift (2005-2009) 39 40 28 27 can-h can-l fan on sig comp on sig pnk wiring diagram
This page shows the only wiring diagram for the component.39 40 28 27 can-h can-l fan on sig comp on sig pnk, which is found in the car Nissan 350Z I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
39 40 28 27 can-h can-l fan on sig comp on sig pnk wiring diagram (1 of 1)
1 11 CAN-H CAN-L PNK WIRE
21 22 BAT IGN
29 30 GND (POWER) GND
39 40 28 27 CAN-H CAN-L FAN ON SIG COMP ON SIG PNK WIRE
49 50 SENS GND SUN SENS
53 54 FAN PWM OUT VACTR
71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 VDD VBL A/C LED
9 19 TX (COMB METER) RX (COMB METER)
A/C CONTROLLER
AIR MIX DOOR MOTOR (BEHIND CENTER OF DASH)
AMBIENT SENSOR (FRONT OF ENGINE COMPT, BEHIND GRILLE)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
FAN ON
FRE LED REC LED
FUSE 11 FUSE 10
FUSE 12
FUSE 19
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
ILL TEMP SW FAN SW MODE SW PUSH SW SW SEL 1 SW SEL 2 SW SEL 3
IN-VEHICLE SENSOR (BEHIND LEFT CENTER OF DASH)
INTAKE DOOR MOTOR (BEHIND RIGHT SIDE OF DASH)
INTAKE SENSOR (BEHIND RIGHT CENTER OF DASH)
LT BLU WIRE
LT GRN WIRE
MODE DOOR MOTOR BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH) (BEHIND CENTER OF DASH)
NCA WIRE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RR/DEF LED
SUNLOAD SENSOR (TOP RIGHT SIDE OF DASH)
UNIFIED METER, A/C AMPLIFIER (UNDER CENTER OF DASH)
VDD VBL A/C LED
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Automatic a/c circuit (1 of 2) -> 39 40 28 27 CAN-H CAN-L FAN ON SIG COMP ON SIG PNK WIRE
