Tire pressure monitoring circuit for Nissan 350Z I (2002-2005)

7 8 21 22 35 BAT GND FLSHER OUT RIGHT FLSHER OUT LEFT IGN ANT INPUT ANTENNA BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BODY CONTROL MODULE (BEHIND LEFT KICK PANEL) COMBINATION METER COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH) DIAG-ID INPUT CAN-H FUSE FUSE 1 FUSE 12 FUSE 14 FUSE 19 FUSE 6 FUSE BLOCK (AT LEFT SIDE OF DASH, BEHIND COVER) FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR SIDE OF ENG COMPT) GND CAN-L HAZARD GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HAZARD HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IGN LOW TIRE PRESSURE WARNING CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN) LT GRN WIRE NCA WIRE PNK WIRE PPL/WHT WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE TIRE PRESSURE TIRE PRESSURE SENSOR TRIP COMPUTER TRIP METER UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH) WHT/BLU WIRE YEL/GRN WIRE
