Car Wiring Diagrams for Radio circuit, except bose for Nissan 350Z I (2002-2005)

1 2 3 4 5 LH FR SP (-) LH FR SP (+) RH FR SP (-) RH FR SP (+) ANT SIG 7 8 9 ILLUM LIGHT SW ANT SIG ANTENNA AMPLIFIER (AT RIGHT "C" PILLAR) AUDIO UNIT AV-NAVI AV-NAVI AV-NAVI AV-NAVI BAT (BACK-UP) BLK WIRE BLK/PNK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE DRIVER'S DOOR SPEAKER DRIVER'S SIDE TWEETER FUSE 37 FUSE 6 FUSE BLOCK (BEHIND LEFT SIDE OF DASH) FUSE, FUSIBLE LINK BOX (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR ACC JOINT CONN (5) JOINT CONN NO. 7 (IN FUSE, FUSIBLE LINK BOX) JOINT CONN NO. 8 (IN FUSE, FUSIBLE LINK BOX) LEFT REAR SPEAKER LH RR SP (-) LH RR SP (+) RH RR SP (-) RH RR SP (+) LT GRN WIRE NAVIGATION SYSTEM NCA WIRE PASSENGER'S DOOR SPEAKER PASSENGER'S DOOR TWEETER RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR SPEAKER ROD ANTENNA WHT/BLK WIRE YEL WIRE YEL/RED WIRE
