Nissan 240SX S14 (1994-1999) up left power window regulator Wiring diagram
This page shows the only wiring diagram for the component.up left power window regulator, which is found in the car Nissan 240SX S14 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram up left power window regulator (1 of 1)
AMP
AUTO D
BLK WIRE
BLU WIRE
CIRCUIT BREAKER (BEHIND LEFT SIDE OF DASH)
DOWN
DRIVER SIDE SWITCH
FUSE BLOCK FUSE 1 (BEHIND LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LOCK
PASSENGER SIDE SWITCH
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY (BEHIND LEFT KICK PANEL)
RED/BLK WIRE
RED/WHT WIRE
RIGHT POWER WINDOW SUB-SWITCH
UNLOCK
UP LEFT POWER WINDOW REGULATOR
UP RIGHT POWER WINDOW REGULATOR
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Power window circuit -> UP LEFT POWER WINDOW REGULATOR
