Nissan 240SX S14 (1994-1999) speedo data in data clk data out sens pwr Wiring diagram

1995 VFTC 3 24 29 30 22 TACHO 50 23 GND A A/T CONTROL UNIT A/T FLUID TEMPERATURE SENSOR TORQUE CONVERTER CLUTCH SOLENOID VALVE ASCD CONTROL UNIT (BEHIND RIGHT KICK PANEL) ASCD UNIT ATCK AUTOMATIC TRANSMISSION AVCC BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE COMBINATION METER DATA LINK CONNECTOR (FOR CONSULT) (LEFT KICK PANEL) DROPPING RESISTOR (LEFT FRONT OF ENGINE COMPT) ENGINE CONTROL MODULE (ECM) (BEHIND RIGHT KICK PANEL) ENGINE COOLANT TEMPERATURE SENSOR (TOP RIGHT FRONT OF ENGINE) FL TEMP TH/SEN SENS GND FUSE 14 FUSE 2 FUSE 8 FUSE BLOCK (LEFT KICK PANEL) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START INHIBITOR SWITCH (RIGHT SIDE OF TRANSMISSION) INSTRUMENT CLUSTER SYSTEM LINE PRESSURE SOLENOID VALVE LT GRN WIRE LT GRN/RED WIRE MEM B/U ENG REV VSP-1 N SIG IDLE SW GND 1 POS 2 POS D POS N POS R POS FULL SW NCA WIRE NEUT O/D OFF IND SPEEDOMETER OD CONT ASCD UNIT ORG/ WIRE ORG/BLK WIRE ORG/GRN WIRE OVERDRIVE CONTROL SWITCH OVERRUN CLUTCH SOLENOID PNK WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE REVOLUTION SENSOR (LEFT SIDE OF TRANSMISSION) SHIFT SOLENOID VALVE SPEEDO DATA IN DATA CLK DATA OUT SENS PWR THROTTLE POSITION SENSOR (ON THROTTLE BODY) THROTTLE POSITION SWITCH (ON THROTTLE BODY) TVOO VEHICLE SPEED SENSOR (RIGHT REAR OF TRANSMISSION) WHT WIRE WHT/RED WIRE WIDE OPEN YEL WIRE YEL/GRN WIRE YEL/RED WIRE
