Nissan 240SX S14 (1994-1999) push control unit Wiring diagram
This page shows the only wiring diagram for the component.push control unit, which is found in the car Nissan 240SX S14 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram push control unit (1 of 1)
A/T INDICATOR ILLUMI- NATION
ASCD MAIN SWITCH
AUDIO ILLUMI- NATION
BLK WIRE
BLU WIRE
CD DECK ILLUMI- NATION
CIGARETTE LIGHTER ILLUMINATION
CLOCK (ILLUMINATION)
COMBINATION METER
FUSE 18
FUSE 4
FUSE BLOCK (BEHIND LEFT KICK PANEL)
GRN/RED WIRE
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ACC OR ON
ILLUMINATION CONTROL SWITCH
LIGHTING SWITCH
OFF
POWER WINDOW MAIN SWITCH ILLUMINATION
PUSH CONTROL UNIT
REAR WINDOW DEFOGGER SWITCH
RED/BLU WIRE
RED/YEL WIRE
Go to component -> Instrument illumination circuit -> PUSH CONTROL UNIT
