Nissan 240SX S14 (1994-1999) fusible link and fuse block 2 Wiring diagram
This page shows the only wiring diagram for the component.fusible link and fuse block 2, which is found in the car Nissan 240SX S14 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fusible link and fuse block 2 (1 of 1)
1994 VFTC
A/C COMPRESSOR CLUTCH
A/C RELAY
A/C RLY
A/C, DEF SWITCH
AMBIENT TEMPERATURE SWITCH (BEHIND CENTER OF GRILLE)
BLK WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/WHT WIRE
COOLING FAN MOTOR 1
COOLING FAN RELAY 1 (IN FUSIBLE LINK AND FUSE BOX)
COOLING FAN RELAY 2 (IN FUSIBLE LINK AND FUSE BOX)
DIODE (CENTER OF I/P)
ECCS CONTROL MODULE (UNDER CENTER OF I/P)
FUSIBLE LINK AND FUSE BLOCK 2
FUSIBLE LINK AND FUSE BLOCK 3
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
HOT AT ALL TIMES FUSE 48
HOT AT ALL TIMES FUSIBLE LINK H
IACV FICD SOLENOID VALVE (RIGHT SIDE OF ENGINE)
ORG/BLK WIRE
ORG/BLU WIRE
PAIR
PD SW
RED WIRE
RF RH
RF RL
TA SW
TRIPLE PRESSURE SWITCH (RIGHT FRONT OF ENGINE COMPT)
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> A/c circuit (2 of 2) -> FUSIBLE LINK AND FUSE BLOCK 2
