Nissan 240SX S14 (1994-1999) cnslt data in cnslt data out cnslt data clk Wiring diagram
This page shows the only wiring diagram for the component.cnslt data in cnslt data out cnslt data clk, which is found in the car Nissan 240SX S14 (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cnslt data in cnslt data out cnslt data clk (1 of 1)
20 21 RX TX
65 64 58 68 SCITX SCIRX KLINE SCICL
ABS CONTROL UNIT (ON LEFT SIDE OF TRUNK)
AIR BAG DIAGNOSIS SENSOR UNIT (BELOW REAR OF CENTER CONSOLE)
BLK WIRE
BRN/YEL WIRE
CNSLT DATA IN CNSLT DATA OUT CNSLT DATA CLK
DATA LINK CONNECTOR (FOR CONSULT) (BEHIND LEFT KICK PANEL, ABOVE FUSE BLOCK)
DATA LINK CONNECTOR (FOR GST) (UNDER LEFT DASH PANEL, NEAR FUSE BOX COVER)
ECCS CONTROL MODULE (ECM) (BEHIND RIGHT KICK PANEL)
FUSE 1
FUSE 8
FUSE BLOCK
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ORG/GRN WIRE
PNK 8 19 9 TX RX DIAGNOSTIC-L WIRE
RED WIRE
TRANSMISSION CONTROL MODULE (BEHIND DASH, LEFT OF STEERING COLUMN)
Go to component -> Computer data lines -> CNSLT DATA IN CNSLT DATA OUT CNSLT DATA CLK
