Nissan 200SX S14 (1993-2000) right front door switch left front door switch Wiring diagrams

A/T A/T M/T BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CLUTCH INTERLOCK RELAY (IN RELAY BOX) CLUTCH INTERLOCK SWITCH (ABOVE CLUTCH) COMBINATION METER SECURITY LAMP FULL STROKE FUSE 10 FUSE 15 FUSE 25 FUSE 26 FUSE 8 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE HOOD SWITCH TRUNK LID KEY CYLINDER SWITCH HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START HOT IN START IGNITION SWITCH INHIBITOR RELAY (IN RELAY BOX) INHIBITOR SWITCH KEY SWITCH L DOOR SW 16 17 24 26 27 28 29 30 31 32 33 DOOR SW LT BLU WIRE LT GRN WIRE LT GRN/RED WIRE M/T M/T A/T OFF PNK WIRE PNK/BLK WIRE R DOOR SW RED WIRE RED/WHT WIRE RIGHT FRONT DOOR SWITCH LEFT FRONT DOOR SWITCH SMART ENTRANCE CONTROL UNIT (BEHIND DASH, RIGHT SIDE OF STEERING COLUMN) STARTER MOTOR THEFT WARNING RELAY (IN RELAY BOX) TRUNK ROOM LAMP SWITCH WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/BLU WIRE

BATTERY BLK WIRE BLU WIRE CIRCUIT BREAKER (BEHIND DASH, LEFT OF FUSE BLOCK) DOOR DOOR SW FUSE FUSE 10 FUSE 15 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT) GROUND HOT AT ALL TIMES HOT IN ON OR ACC INTERIOR LAMP KEY SW KEY SWITCH LEFT REAR DOOR SWITCH OFF ON PNK WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT DOOR SWITCH LEFT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH ROOM LAMP SMART ENTRANCE CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN) TRUNK ROOM LAMP TRUNK ROOM LAMP SWITCH WHT WIRE WHT/BLU WIRE
