Nissan 200SX S14 (1993-2000) main power window, door lock/ unlock switch Wiring diagram

1 2 3 BAT UNLOCK OUTPUT UNLOCK OUTPUT LOCK OUTPUT BETWEEN LOCK FULL STROKE AND N BETWEEN UNLOCK FULL STROKE AND N BLK WIRE BLU WIRE BLU/ORG WIRE CIRCUIT BREAKER (BEHIND DASH, LEFT OF FUSE BLOCK) FUSE 15 FUSE 8 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GRN WIRE GRN/RED WIRE GRN/YEL WIRE GROUND IGN UNLOCK SENSE UNLOCK SENSE UNLOCK SENSE 1 1 1 1 GRY WIRE HOT AT ALL TIMES HOT IN ON OR START KEY SWITCH L DOOR SW LOCK UNLOCK PPL 1 1 1 1 KEY SW KEY CYL SW KEY CYL SW R DOOR SW LEFT "C" PILLAR) LEFT DOOR KEY CYLINDER SWITCH LEFT FRONT DOOR LOCK ACTUATOR LEFT FRONT DOOR SWITCH LEFT REAR DOOR LOCK ACTUATOR LOCK LT GRN/RED WIRE MAIN POWER WINDOW, DOOR LOCK/ UNLOCK SWITCH PNK WIRE PPL RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT DOOR KEY CYLINDER SWITCH RIGHT DOOR LOCK/ UNLOCK SWITCH RIGHT FRONT DOOR LOCK ACTUATOR RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR LOCK ACTUATOR SMART ENTRANCE CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN) UNLOCK W/ MULTI-REMOTE CONTROL SYSTEM WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
