Nissan 200SX S14 (1993-2000) left right turn turn ind ind Wiring diagram
This page shows the only wiring diagram for the component.left right turn turn ind ind, which is found in the car Nissan 200SX S14 (1993-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left right turn turn ind ind (1 of 1)
26 27 16 17 (W/ TACH) (W/O TACH)
ANTI-LOCK BRAKES, SHIFT INTERLOCK, CRUISE CONTROL SYSTEMS
BLK WIRE
BLU WIRE
COM- BINATION SWITCH (TURN SIGNAL SWITCH)
COMBINATION FLASHER UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN)
COMBINATION SWITCH (LIGHTING SWITCH)
FUSE 11
FUSE 14
FUSE 20
FUSE 36
FUSE BLOCK (BEHIND DASH, LEFT OF COLUMN)
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT, NEXT TO BATTERY)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD ON
HAZARD SWITCH
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
LEFT FRONT COMBIN- ATION LAMP
LEFT FRONT TURN LIGHT
LEFT LICENSE LIGHT
LEFT REAR COM- BINATION LAMP
LEFT RIGHT TURN TURN IND IND
LT GRN WIRE
LT GRN/BLK WIRE
MULTI-REMOTE CONTROL RELAY 1 (IN RELAY BOX)
MULTI-REMOTE CONTROL RELAY 2 (IN FUSIBLE LINK BOX)
NCA WIRE
OFF
ORG/ WIRE
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RH LH
RIGHT FRONT COMBIN- ATION LAMP
RIGHT FRONT TURN LIGHT
RIGHT LICENSE LIGHT
RIGHT REAR COM- BINATION LAMP
SMART ENTRANCE CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN)
STOP LAMP SWITCH
STOP TURN
TAIL
TAIL STOP TURN
W/ MULTI REMOTE
W/ SPOILER
W/O MULTI REMOTE
W/O SPOILER
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> LEFT RIGHT TURN TURN IND IND
