Nissan 200SX S14 (1993-2000) engine controls system, interior lights system, warning systems Wiring diagram
This page shows the only wiring diagram for the component.engine controls system, interior lights system, warning systems, which is found in the car Nissan 200SX S14 (1993-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine controls system, interior lights system, warning systems (1 of 1)
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/RED WIRE
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM HEADLIGHTS SYSTEM
ENGINE CONTROLS SYSTEM, INTERIOR LIGHTS SYSTEM, WARNING SYSTEMS
ENGINE CONTROLS SYSTEM, THROTTLE POSITION SWITCH
FROM FUSE BLOCK (DIAGRAM 2 OF 3)
FROM HEADLAMP SWITCH PIN 12 (DIAGRAM 1 OF 3)
FROM IGNITION SWITCH PIN 6 (DIAGRAM 1 OF 3)
FUSE 17
FUSE 21
FUSE 22
FUSE 25
FUSE 26
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GRN WIRE
RED/BLU WIRE
RED/GRN WIRE
STARTING/ CHARGING SYSTEM ANTI-THEFT SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
Go to component -> Power distribution circuit (3 of 3) -> ENGINE CONTROLS SYSTEM, INTERIOR LIGHTS SYSTEM, WARNING SYSTEMS
