Nissan 200SX S14 (1993-2000) combination meter Wiring diagrams

1995 VFTC A/T DEVICE (OVERDRIVE CONTROL SWITCH) AVCC BLK WIRE BRN/YEL WIRE COMBINATION METER DIODE (BEHIND LEFT SIDE OF GLOVE BOX, TAPE TO HARN) ECCS CONTROL MODULE (ECM) (BELOW CENTER OF DASH) ENGINE COOLANT TEMPERATURE SENSOR (TOP FRONT OF OF ENGINE) FUSE 12 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GND A GRN/ORG WIRE GRY WIRE HOT IN ON OR START INHIBITOR SWITCH (ON LEFT SIDE OF TRANSAXLE) J/C 1 (BEHIND CENTER OF DASH) J/C 2 (BEHIND CENTER OF DASH) LKUP NCA WIRE NEUT O/D CANCEL SOLENOID VALVE O/D OFF IND ORG/ WIRE PNK/BLK WIRE PNK/BLU WIRE TCC SOLENOID VALVE THROTTLE POSITION SENSOR (ON THROTTLE BODY ASSEMBLY) TRANSMISSION W/0 CRUISE CONTROL W/CRUISE CONTROL YEL WIRE

51 49 23 W/TMP AVCC A/T DEVICE (OVERDRIVE SWITCH) A/T FLUID TEMPERATURE SENSOR (ON TRANSAXLE) ASCD CONTROL UNIT (BEHIND LEFT SIDE OF DASH) AUTOMATIC TRANSAXLE BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE CLSD SW GND 1 POS 2 POS D POS P/N POS R POS WO SW CLUSTER SYSTEM CLUTCH SOLENOID VALVE COMBINATION METER CRUIS SW DATA LINK CONNECTOR (FOR CONSULT) (BEHIND DASH, NEXT TO FUSE BLOCK) DROPPING RESISTOR (LEFT FRONT OF ENGINE COMPARTMENT) ECCS CONTROL MODULE (ECM) (BELOW CENTER OF DASH) ENGINE CONTROLS SYSTEM (TACHOMETER) ENGINE COOLANT TEMPERATURE SENSOR (FRONT SIDE OF ENGINE) FL TEMP TH/SENS SENS GND FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GND A GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES FUSE 15 FUSE 7 HOT IN ON OR START HOT IN ON OR START FUSE 12 HOT IN ON OR START FUSE 18 HOT IN ON OR START FUSE 8 INHIBITOR SWITCH (ON LEFT SIDE OF TRANSAXLE) INSTRUMENT J/C 1 LINE PRESSURE SOLENOID VALVE LT BLU WIRE LT GRN WIRE NCA WIRE O/D OFF IND OD CONT ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE PNK MEM B/U TACHO VSP-1 WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PPL PPL ATCK PPL/RED WIRE RED WIRE RED/WHT WIRE REVOLUTION SENSOR (ON TRANSAXLE) RUN WIRE SHIFT SOLENOID VALVE SHIFT SOLENOID VALVE OVER- TORQUE CONVERTER CLUTCH SOLENOID VALVE SPEEDOMETER TACHO THROTTLE POSITION SENSOR (ON THROTTLE BODY ASSEMBLY) THROTTLE POSITION SWITCH (ON THROTTLE BODY) CLOSED TRANSMISSION CONTROL MODULE (BEHIND LEFT KICK PANEL) TVO VEHICLE SPEED SENSOR (TOP RIGHT SIDE OF TRANSAXLE) VSP VSP-2 DATA IN DATA CLK DATA OUT SENS PWR WHT WIRE WHT/GRN WIRE WOT YEL WIRE

ABS ACTUATOR (RIGHT REAR CORNER OF ENGINE COMPT) ABS CONTROL UNIT (BEHIND RIGHT KICK PANEL) ABS RELAY UNIT (RIGHT FRONT STRUT TOWER) ABS WARNING LAMP BLK WIRE BLS BLU WIRE BLU/BLK WIRE BRN WIRE BRN/WHT WIRE COMBINATION METER FL IN FL IN RR IN MR FL OUT FL OUT RR OUT PPL FL SS FL GND RR SS RL GND RL SS FR GND FR SS DIAG L FR IN PPL FR OUT FUSE 12 FUSE 14 FUSE BLOCK (UNDER LEFT SIDE OF DASH) FUSE 28 FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT) FUSIBLE LINK C FUSIBLE LINK D GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START LEFT FRONT WHEEL SPEED SENSOR LEFT REAR WHEEL SPEED SENSOR LT GRN WIRE LT GRN/RED WIRE MOTOR RELAY NCA WIRE ORG/BLK WIRE PNK WIRE PPL PPL/WHT WIRE RED WIRE RED/GRN WIRE RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR WHEEL SPEED SENSOR RL IN RL IN FR IN RL OUT RL OUT FR OUT RR IN RR OUT ABS MOTOR RXD UM SILA SOLENOID VALVE RELAY STOP LAMP SWITCH TXD VR RR GND GND WHT WIRE YEL WIRE

1 2 DATA LINK CONNECTOR (BEHIND DASH, NEAR FUSE BOX COVER) AIR BAG DIAGNOSIS SENSOR UNIT (BELOW REAR OF CENTER CONSOLE) AIR BAG IND BLK WIRE BLU WIRE BRN/WHT WIRE COMBINATION METER DOOR SW DRIVER AIR BAG MODULE FUSE 12 FUSE 22 FUSE BLOCK (J/B) GRN WIRE GRN/BLK WIRE GRY/BLU WIRE HOT IN ON OR START ORG/ WIRE PASSENGER AIR BAG MODULE RED WIRE RED/BLU WIRE SPIRAL CABLE SSS RX SSS TX W/ TACH W/L LED W/O TACH WHT WIRE YEL WIRE

BATTERY BLK WIRE BLU WIRE CIRCUIT BREAKER (BEHIND DASH, LEFT OF FUSE BLOCK) COMBINATION METER COMBINATION SWITCH (LIGHTING SWITCH) FUSE FUSE 12 FUSE 15 FUSE 36 FUSE 8 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT) GRN WIRE GROUND HOT AT ALL TIMES HOT IN ON OR START IGNITION IND KEY SW KEY SWITCH LEFT "C" PILLAR) LEFT DOOR SW LEFT FRONT DOOR SWITCH LIGHT SW OFF PNK WIRE RED WIRE RED/GRN WIRE SEAT BELT SEAT BELT SW- SEAT BELT SWITCH SMART ENTRANCE CONTROL UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE

BLK WIRE BLU WIRE COMBINATION METER COMBINATION SWITCH (LIGHTING SWITCH) FUSE 12 FUSE 15 FUSE 36 FUSE 8 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT) GRN WIRE GROUND HOT AT ALL TIMES HOT IN ON OR START IGNITION IND KEY SW KEY SWITCH LEFT "C" PILLAR) LEFT DOOR SW LEFT FRONT DOOR SWITCH LIGHT SW OFF PNK WIRE RED WIRE RED/GRN WIRE SEAT BELT SEAT BELT SW- SEAT BELT SWITCH WARNING CHIME UNIT (BEHIND DASH, RIGHT OF STEERING COLUMN) WHT WIRE WHT/BLK WIRE YEL WIRE
