Nissan 200SX S14 (1993-2000) 68 65 64 58 scicl scitx scirx kline Wiring diagram
This page shows the only wiring diagram for the component.68 65 64 58 scicl scitx scirx kline, which is found in the car Nissan 200SX S14 (1993-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 68 65 64 58 scicl scitx scirx kline (1 of 1)
18 46 16 RXD TXD DIAGL
20 21 SSS RX SSS TX
29 30 28 CNSLT DATA CLK CNSLT DATA OUT CNSLT DATA IN
68 65 64 58 SCICL SCITX SCIRX KLINE
ABS CONTROL UNIT (BEHIND RIGHT KICK PANEL)
AIR BAG DIAGNOSIS SENSOR UNIT (BELOW REAR OF CENTER CONSOLE)
BLK WIRE
BLU/BLK WIRE
DATA LINK CONNECTOR (FOR CONSULT) (BEHIND DASH, NEXT TO FUSE BLOCK)
DATA LINK CONNECTOR (FOR GST) (UNDER LEFT DASH PANEL)
ECCS CONTROL MODULE (ECM) (BELOW CENTER OF DASH)
FUSE 15
FUSE 8
FUSE BLOCK
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ORG/BLK WIRE
PNK WIRE
TRANSMISSION CONTROL MODULE (2.0L ONLY) (BEHIND LEFT KICK PANEL)
Go to component -> Computer data lines -> 68 65 64 58 SCICL SCITX SCIRX KLINE
