Nissan 200SX S14 (1993-2000) 1 2 3 4 5 res/acc sw set/coast sw ground main switch brake n/c sw Wiring diagram

1 2 3 4 5 RES/ACC SW SET/COAST SW GROUND MAIN SWITCH BRAKE N/C SW A/T A/T A/T A/T CONTROL VALVE (REAR OF TRANSMISSION) AIR VALVE SOLENOID ASCD BRAKE SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) (A/T) ASCD BRAKE SWITCH (TOP OF BRAKE PEDAL SUPPORT) (M/T) ASCD CLUTCH SWITCH ASCD CONTROL UNIT (BEHIND DASH, LEFT OF STEERING COLUMN) ASCD HOLD RELAY (BEHIND LEFT SIDE OF DASH) (A/T) ASCD HOLD RELAY (BEHIND LEFT SIDE OF DASH) (M/T) ASCD MAIN SWITCH ASCD PUMP (LEFT REAR CORNER OF ENGINE COMPARTMENT) ASCD STEERING SWITCH BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CRUISE IND ECM (BELOW CENTER OF DASH) FUSE 14 FUSE 25 FUSE 42 FUSE 8 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT, NEXT TO BATTERY) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED (OR BRN) WIRE GRN/RED WIRE GRN/WHT (OR GRN/RED) WIRE GRN/WHT WIRE GRN/YEL WIRE HORN RELAY (RELAY BOX, RIGHT SIDE OF ENGINE COMPT) HORNS SYSTEM HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER INTERIOR LIGHTS M/T MANUAL TRANSMISSION AUTOMATIC TRANSMISSION OFF ORG/ WIRE ORG/BLK WIRE PNK WIRE PPL/RED WIRE RED WIRE RED/GN WIRE RED/GRN WIRE RED/YEL WIRE RED/YL WIRE RELEASE VALVE SOLENOID RESUME/ ACCELERATE SET/COAST SPEED- OMETER SPIRAL CABLE STOP LAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) SYSTEM TRANS. SYSTEM VACUUM MOTOR VEHICLE SPEED SENSOR (TOP OF TRANS.) VSP W/ TACHOMETER W/O TACHOMETER YEL WIRE
