Mitsubishi RVR III facelift 3 (2019-2024) sunshade switch Wiring diagrams
This page contains all the electrical diagrams for the component. sunshade switch, in which he is found in the car Mitsubishi RVR III facelift 3 (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sunshade switch (1 of 2)
A-43
A-49
A-52
A-61
B-27
BLK WIRE
BRN WIRE
E-05
E-051
E-06
E-10
E-13
E-14
ENGINE CONTROL MODULE
FCM/LDW/ AHB-ECU
FRONT DOME LIGHT
GRY WIRE
HALOGEN TYPE
HOOD LATCH SWITCH
INJECTOR RELAY
INSIDE REAR VIEW MIRROR ASSEMBLY
LEFT FOG LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT ASSEMBLY
LEFT SUNSHADE ILLUMINATION
LEFT VANITY MIRROR LIGHT
LIGHTING CONTROL SENSOR
NCA WIRE
REAR DOME LIGHT
RIGHT FOG LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT ASSEMBLY
RIGHT SUNSHADE ILLUMINATION
RIGHT VANITY MIRROR LIGHT
STARTER RELAY
SUNSHADE ILLUMINATION CHANGEOVER SWITCH
SUNSHADE MOTOR ASSEMBLY
SUNSHADE SWITCH
W/ AUTO LIGHT
W/O PANORAMA
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 4) -> SUNSHADE SWITCH
Wiring diagram sunshade switch (2 of 2)
Go to component -> Power top/sunroof circuit -> SUNSHADE SWITCH
