Mitsubishi RVR III facelift 3 (2019-2024) main switch Wiring diagram
This page shows the only wiring diagram for the component.main switch, which is found in the car Mitsubishi RVR III facelift 3 (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram main switch (1 of 1)
BLK WIRE
BRN WIRE
C-226
C-415
C-416
CLOSE
ETACS-ECU
FRONT LIGHT SENSOR
FUSE 15
FUSE 16
GARAGE DOOR OPENER SWITCH 1
GARAGE DOOR OPENER SWITCH 2
GARAGE DOOR OPENER SWITCH 3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY 2 ENERGIZED
IND
INSIDE REAR VIEW MIRROR ASSEMBLY
J/C 1 (C-231)
MAIN SWITCH
REAR LIGHT SENSOR
RED WIRE
VIO WIRE
YEL WIRE
Go to component -> Automatic day/night mirror circuit -> MAIN SWITCH
