Mitsubishi RVR III facelift 3 (2019-2024) grn Wiring diagrams

A/B A/C CONTROL PANEL A/C SWITCH A/C SWITCH INDICATOR AA- ACP AIR MIXING DAMPER CONTROL MOTOR (LOWER RIGHT SIDE OF HVAC UNIT) AMBIENT AIR TEMPERATURE SENSOR ANALOG INTERFACE CIRCUIT B/UP BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER RELAY BLOWER SPEED SELECTION DIAL BLU WIRE BRN WIRE C-216 C-410 C-411 C-415 C-417 CAN DRIVE CIRCUIT CAN L COMPUTER DATA LINES SYSTEM ETACS-ECU FA' PNK FB' C-232 WIRE FUSE 12 FUSE 8 FUSIBLE LINK 1 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES IG 1 ILO+ INC INTERFACE CIRCUIT J/C 2 (C-04) LT BLU WIRE LT GRN WIRE MA' MB' MODE SELECTION DAMPER CONTROL MOTOR MODE SELECTION DIAL OFF OUTSIDE/ INSIDE AIR SELECTION INDICATOR OUTSIDE/ INSIDE AIR SELECTION SWITCH OUTSIDE/INSIDE AIR SELECTION DAMPER CONTROL MOTOR P/TB PNK WIRE REAR WINDOW DEFOGGER INDICATOR REAR WINDOW DEFOGGER SWITCH RED WIRE RELAY ENERGIZED SENB SENG TAN WIRE TEMPERATURE CONTROL DIAL VIO WIRE WHT WIRE YEL WIRE YEL/BLU WIRE

A/C CONTROL PANEL BLK WIRE BLU WIRE BRN WIRE C-212 C-225 C-26 C-411 C-417 CAN DRIVE CIRCUIT CAN L COMPUTER DATA LINES SYSTEM ETACS-ECU FUSE 12 FUSE 22 FUSIBLE LINK 21 G-03 G-22 G-23 GRN WIRE GROUNDING CONNECTOR (C-01) GRY WIRE HOT AT ALL TIMES J/C 2 (C-04) LEFT DOOR MIRROR ASSEMBLY LT BLU WIRE NAVIGATION SYSTEM NCA WIRE PASSENGER COMPARTMENT RELAY BOX REAR WINDOW DEFOGGER REAR WINDOW DEFOGGER RELAY RED WIRE RIGHT DOOR MIRROR ASSEMBLY TAN WIRE VIO WIRE WHT WIRE YEL WIRE

A-52 ANTI-LOCK BRAKES SYSTEM BLK WIRE BLU WIRE C-28 C-403 C-411 C-413 C-417 ETACS-ECU FIELD EFFECT TRANSISTOR DRIVE CIRCUIT FIELD-EFFECT TRANSISTOR FUSE 10 FUSE 2 G-23 GRN WIRE GRY WIRE HIGH MOUNTED STOPLIGHT HOT AT ALL TIMES INPUT CIRCUIT INTERIOR LIGHTS, SEATS SYSTEMS LEFT FRONT TURN SIGNAL LIGHT LEFT HEADLIGHT ASSEMBLY LEFT LICENSE PLATE LIGHT LEFT REAR COMBINATION LIGHT ASSEMBLY LEFT SIDE TURN SIGNAL LIGHT LT BLU WIRE LT GRN WIRE NCA WIRE PARKING, DRL PNK PNK WIRE PNK WIRE RED WIRE RIGHT FRONT TURN SIGNAL LIGHT RIGHT HEADLIGHT ASSEMBLY RIGHT LICENSE PLATE LIGHT RIGHT REAR COMBINATION LIGHT ASSEMBLY RIGHT SIDE TURN SIGNAL LIGHT STOP LIGHT STOPLIGHT RELAY STOPLIGHT SWITCH TAILLIGHT CONTROL CIRCUIT TAILLIGHT/SIDE MARKER LIGHT TRANSMISSION SYSTEM TURN SIGNAL TURN SIGNAL LIGHT CONTROL CIRCUIT VIO WIRE W/ STOPLIGHT RELAY W/O STOPLIGHT RELAY WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE C-212 C-225 C-226 C-411 C-412 C-416 C-417 CAN DRIVE CIRCUIT CIRCUIT COLUMN ECU COLUMN SWITCH COMBINATION METER COMPUTER DATA LINES SYSTEM ETACS-ECU FUSE 12 FUSE 8 FUSE 9 GRN WIRE GROUNDING CONNECTOR (C-01) HAZARD INDICATOR ASSEMBLY HAZARD WARNING SWITCH HEAD HEAD- LIGHTS SYSTEM HOT AT ALL TIMES INTERFACE J/C 3 (C-102) LED DRIVE LEFT DOOR MIRROR ASSEMBLY LEFT TURN IND LEFT TURN SIGNAL LIGHTING CONTROL SENSOR LIGHTING SWITCH LIN DRIVE CIRCUIT LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RELAY ENERGIZED RIGHT DOOR MIRROR ASSEMBLY (IF EQUIPPED) RIGHT TURN IND RIGHT TURN SIGNAL TAIL TAIL IND TAN WIRE TRANSCEIVER/ VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

+B C-10 12 11 PNK WIRE A-66 BLK WIRE BLU WIRE BRN WIRE C-403 C-410 C-411 C-412 C-413 C-415 C-417 C-417 8 CAN DRIVE CIRCUIT CAN TRANSCEIVER CIRCUIT COMBINATION METER COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT RELAY BOX ETACS-ECU (LEFT END OF DASH) ETH (-) FUSE 12 FUSE 8 FUSE 9 G-23 GRN WIRE GROUNDING CONNECTOR (C-01) GRY WIRE HAZARD INDICATOR ASSEMBLY HEADLIGHT BACKUP CIRCUIT HEADLIGHTS SYSTEM HOOD LATCH SWITCH HORNS SYSTEM HOT AT ALL TIMES IGNITION CONTROL CIRCUIT INDICATOR J/C 4 (C-108) KEY REMINDER SWITCH KOS ECU LCD (THEFT ALARM) LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR) LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR) LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR) RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR) TAILGATE LATCH SWITCH THEFT- ALARM HORN THEFT-ALARM HORN RELAY THEFT-ALARM INDICATOR TONE ALARM TURN-SIGNAL LIGHT CONTROL UHF RECEIVER VIO WIRE W/ ONE TOUCH START W/O ONE TOUCH START WHT WIRE WIRELESS CONTROL MODULE YEL WIRE

ANTG ANTP BLK WIRE BLU WIRE C-417 COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE ETACS-ECU ETH (-) FUSE 12 FUSE 8 GRN WIRE GROUNDING CONNECTOR (C-01) HOT AT ALL TIMES J/C 2 (C-04) J/C 3 (C-102) J/C 4 (C-231) KEY REMINDER SWITCH LT BLU WIRE LT GRN WIRE NCA WIRE RED WIRE RELAY ENERGIZED TAN WIRE TRANSPONDER KEY VIO WIRE WHT WIRE WIRELESS CONTROL MODULE

AIR BAG OFF INDICATOR LIGHT (PASSENGER'S SIDE) BLK WIRE BLU WIRE BRN WIRE C-412 C-417 CLH - CLS CONNECTOR LOCK SWITCH CRH - CRS DBS- DBSO DRIVER'S SIDE SEAT BELT SWITCH, ETACS-ECU FUSE 12 FUSE 18 GRN WIRE GRY WIRE HAZARD INDICATOR ASSEMBLY INTERFACE CIRCUIT J/C 2 (C-04) LT BLU WIRE LT GRN WIRE NCA WIRE OFF OFF ON PASSENGER'S SEAT BELT IND PASSENGER'S SIDE SEAT BELT SWITCH PBS- PBSO PNK WIRE POWER DISTRIBUTION SYSTEM PTA PTD+ RED WIRE RIGHT FRONT SIDE IMPACT SENSOR RIGHT REAR SIDE IMPACT SENSOR SLS+ SOLID STATE SRS SRS ECU SSL- SSR+ SSR+ C-124 TAN WIRE VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE

BRN WIRE CONNECTOR LOCK SWITCH GRN WIRE GRY WIRE LEFT CURTAIN AIR BAG MODULE SQUIB (ROOF RAIL, NEAR TOP OF LEFT "C" PILLAR) LEFT FRONT SIDE IMPACT SENSOR LEFT REAR SIDE IMPACT SENSOR LT BLU WIRE LT GRN WIRE NCA WIRE OFF OFF ON ON OFF ON OFF ON PNK WIRE RED WIRE RIGHT CURTAIN AIR BAG MODULE SQUIB (ROOF RAIL, NEAR TOP OF RIGHT "C" PILLAR) SOLID STATE TAN WIRE TRANSMISSION SYSTEM VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE

BLK WIRE BLU WIRE BRN WIRE BTT C-26 C-411 CAN DRIVE CIRCUIT CAN TRANSCEIVER CIRCUIT CANL CANH CAPACITOR SENSOR COMBINATION METER COMPUTER DATA LINES SYSTEM D-48-1 D-48-2 DRIVER SEAT BELT IND ETACS-ECU GRN WIRE GRY WIRE GUARD GUARD A INTERFACE CIRCUIT LCD (SRS) LED DRIVE CIRCUIT LT BLU WIRE LT GRN WIRE NCA WIRE OCCUPANT CLASSIFICATION ECU PNK WIRE RED WIRE SEAT SLIDE SENSOR SENSE SENSE C SHIELD (GUARD) SRS IND TAN WIRE VIO WIRE WHT WIRE YEL WIRE

ASQ- BLK WIRE BRN WIRE C-127 C-303 C-316 CAN (+) CAN+ C-126 CLOCKSPRING COMPUTER DATA LINES SYSTEM CONNECTOR LOCK SWITCH DRIVER'S KNEE AIR BAG MODULE SQUIB (LOWER LEFT SIDE OF DASH) FLH- FRH- GRN WIRE GRY WIRE KDS+ LEFT FRONT IMPACT SENSOR LT BLU WIRE LT GRN WIRE NCA WIRE OFF OFF ON OFLP ON OFF PNK WIRE RIGHT FRONT IMPACT SENSOR SOLID STATE SRS ECU VIO WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE
