Mitsubishi RVR III facelift 3 (2019-2024) condenser fan relay Wiring diagrams
This page contains all the electrical diagrams for the component. condenser fan relay, in which he is found in the car Mitsubishi RVR III facelift 3 (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram condenser fan relay (1 of 3)
A-17
A-54
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY
A/C COMPRESSOR, CLUTCH ASSEMBLY (LOWER LEFT FRONT OF ENGINE)
A/C PRESSURE SENSOR
AC/R
BLK WIRE
BLU WIRE
BRN WIRE
C-128
CANL B-27
COMPUTER DATA LINES SYSTEM
CONDENSER FAN MOTOR
CONDENSER FAN RELAY
ENGINE COMPARTMENT RELAY BOX
ENGINE CONTROL MODULE
ENGINE COOLANT TEMPERATURE SENSOR
FAN CONTROL RELAY
FIN THERMO SENSOR
FUSE 7
FUSIBLE LINK 28
FUSIBLE LINK 29
GRY WIRE
HOT AT ALL TIMES
INTERIOR TEMPERATURE SENSOR
LT GRN WIRE
NCA WIRE
PNK WIRE
RADIATOR FAN MOTOR (BEHIND RADIATOR)
RADIATOR FAN RELAY
RED WIRE
VIO WIRE
WHT WIRE
WTS B-26
WTSE
YEL WIRE
YEL/BLU WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> CONDENSER FAN RELAY
Wiring diagram condenser fan relay (2 of 3)
A-54
ANALOG
ANALOG INTERFACE CIRCUIT
BLK WIRE
BLU WIRE
BRN WIRE
C-410
C-411
CAN DRIVE CIRCUIT
CANL B-27
COMPUTER DATA LINES SYSTEM
CONDENSER FAN MOTOR
CONDENSER FAN RELAY
ENGINE COMPARTMENT RELAY BOX
ENGINE CONTROL MODULE
ENGINE COOLANT TEMPERATURE SENSOR
ETACS-ECU
FAN CONTROL RELAY
FUSIBLE LINK 28
FUSIBLE LINK 29
HOT AT ALL TIMES
INTERFACE CIRCUIT
NCA WIRE
PNK WIRE
RADIATOR FAN MOTOR
RADIATOR FAN RELAY
RED WIRE
WHT WIRE
WTS (+)
WTSE B-26
YEL WIRE
Go to component -> Cooling fan circuit -> CONDENSER FAN RELAY
Wiring diagram condenser fan relay (3 of 3)
A-17
A/C COMPRESSOR CLUTCH RELAY
ASC-ECU
AUDIO AMPLIFIER
B-117
B-27
BLU WIRE
BRN WIRE
C-130
C-15
CONDENSER FAN RELAY
D-07
DAYTIME RUNNING LIGHT RELAY
ENGINE COMPARTMENT RELAY BOX
ENGINE CONTROL MODULE
FAN CONTROL RELAY
FOG LIGHT RELAY
FROM FUSIBLE LINK BOX (DIAGRAM 1 OF 6)
FUSE 1
FUSE 10
FUSE 11 N/A
FUSE 12 N/A
FUSE 13
FUSE 2 FUSE 31
FUSE 3
FUSE 30
FUSE 4
FUSE 5
FUSE 6 N/A
FUSE 7
FUSE 8
FUSE 9
FUSIBLE LINK 24
FUSIBLE LINK 26
FUSIBLE LINK 27
FUSIBLE LINK 28
FUSIBLE LINK 29
GENERATOR
GRN WIRE
GRY WIRE
HEADLIGHT RELAY (HIGH)
HEADLIGHT RELAY (LOW)
HEATED STEERING WHEEL RELAY
HORN RELAY
LT BLU WIRE
LT GRN WIRE
MFI RELAY
PNK WIRE
RADIATOR FAN RELAY
RED WIRE
STARTER RELAY
THEFT-ALARM HORN RELAY
THROTTLE ACTUATOR CONTROL MOTOR RELAY
TO ETACS-ECU (DIAGRAM 6 OF 6)
TRANSAXLE CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> CONDENSER FAN RELAY
