Car Wiring Diagrams for Rear sonar circuit for Mitsubishi Outlander IV (2021-2024)

BLU WIRE BRN WIRE CAMERA CONTROL UNIT D-01 D-15 D-40 D-61 D-90 D-94 D-95 D-96 ETACS-ECU FUSE 40 GRN WIRE HOT W/ ACCESSORY RELAY ENERGIZED J/C 19 (D-10) LEFT FRONT INNER SONAR SENSOR LEFT FRONT OUTER SONAR SENSOR LEFT FRONT SIDE SONAR SENSOR LEFT REAR INNER SONAR SENSOR LEFT REAR OUTER SONAR SENSOR LEFT SIDE REAR SONAR SENSOR (LEFT END OF REAR BUMPER) LT BLU WIRE LT GRN WIRE PNK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE RED WIRE SONAR CONTROL UNIT TAN WIRE VIO WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE D-01 D-106 D-107 D-62 D-90 GRN WIRE GRY WIRE J/C 24 (D-59) J/C 25 (D-66) (RIGHT "D" PILLAR) J/C 26 (D-67) LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE RED WIRE RIGHT FRONT INNER SONAR SENSOR RIGHT FRONT OUTER SONAR SENSOR RIGHT FRONT SIDE SONAR SENSOR RIGHT REAR INNER SONAR SENSOR RIGHT REAR OUTER SONAR SENSOR RIGHT SIDE REAR SONAR SENSOR SONAR CONTROL UNIT TAN WIRE VIO WIRE WHT WIRE YEL WIRE
