Exterior lamps circuit for Mitsubishi Outlander IV (2021-2024)

A-78 A-81 A-82 BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE C-02 C-04 C-05 C-12 COLUMN SWITCH COMPUTER DATA LINES SYSTEM D-06 D-07 D-15 D-81 ETACS-ECU FUSE 15 FUSE 21 FUSE 32 FUSE 6 GRN WIRE GRY WIRE HIGH MOUNTED STOP LIGHT HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED J/C 28 (D-76) J/C 33 (G-11) LEFT REAR COMBINATION LIGHT LIFTGATE LIGHT LT BLU WIRE LT GRN WIRE PNK WIRE PPL/BRN WIRE PPL/RED WIRE PPL/YEL WIRE RED WIRE RIGHT REAR COMBINATION LIGHT STOP LIGHT SWITCH TAN WIRE VIO WIRE WHT WIRE YEL WIRE

A-32 A-35 A-41 A-42 A-43 A-46 BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM CONTROL MODULE D-11 D-81 GRN WIRE GRY WIRE HOT AT ALL TIMES IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) J/C 33 (G-11) LEFT BACKUP LIGHT LEFT FRONT COMBINATION LIGHT LEFT HEADLIGHT ASSEMBLY LEFT LICENSE PLATE LIGHT LT BLU WIRE PARKING LAMP/ DAYTIME RUNNING LIGHT PNK WIRE PPL/BLU WIRE PPL/BRN WIRE PPL/RED WIRE RED WIRE RIGHT BACKUP LIGHT RIGHT FRONT COMBINATION LIGHT RIGHT HEADLIGHT ASSEMBLY RIGHT LICENSE PLATE LIGHT SMART FET TAN WIRE VIO WIRE WHT WIRE YEL WIRE
