Mitsubishi Outlander IV (2021-2024) windshield wiper motor Wiring diagrams

A-08 A-09 A-31 A-32 A-34 A-35 A-41 A-43 A-71 A-75 A/C COMPRESSOR CLUTCH ASSEMBLY ACTIVE GRILLE SHUTTER B-02 B-12 B-62 BLK WIRE BRAKE FLUID LEVEL SWITCH CONDENSER EGR VOLUME CONTROL VALVE SHIELD ELECTRIC INTAKE VALVE TIMING CONTROL ACTUATOR ELECTRIC INTAKE VALVE TIMING CONTROL ACTUATOR SHIELD ELECTRIC INTAKE VALVE TIMING CONTROL MOTOR SHIELD ELECTRIC INTAKE VALVE TIMING CONTROL POSITION SENSOR SHIELD ENGINE CONTROL MODULE ENGINE CONTROL MODULE SHIELD FCM/LDW/ AHB-ECU FUEL PUMP MODULE FUEL RELAY GRY WIRE HOOD LATCH SWITCH HORN (HIGH) IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) J/C 1 (A-74) J/C 5 (B-15) J/C 6 (B-16) LEFT HEADLIGHT ASSEMBLY POWER DOOR LOCK WARNING BUZZER PRIMARY PULLEY SPEED SENSOR PTC HEATER RADIATOR FAN MOTOR REAR WINDOW WASHER RELAY RIGHT FRONT COMBINATION LIGHT RIGHT FRONT FOG LIGHT RIGHT HEADLIGHT ASSEMBLY SECONDARY PULLEY SPEED SENSOR SELECTOR LEVER ASSEMBLY SPARE CONNECTOR (SWITCH BOX) STEERING WHEEL SENSOR TRANSAXLE CONTROL MODULE TURBINE SPEED SENSOR WINDSHIELD WASHER RELAY WINDSHIELD WIPER MOTOR

A-38 A-41 A-43 A-44 A-45 A-46 A-48 BCM (BODY CONTROL MODULE) (LEFT END OF DASH) BLK WIRE BLU WIRE BRN WIRE C-01 C-05 C-12 COLUMN SWITCH COMBINATION METER COMPUTER DATA LINES SYSTEM D-06 D-07 D-08 D-15 D-79 D-81 ETACS-ECU FRONT WASHER TANK FUSE 110 FUSE 15 FUSE 29 FUSE EE FUSE J GRN WIRE GRY WIRE HEADLAMP WASHER RELAY HEADLIGHT WASHER MOTOR HOT AT ALL TIMES IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) JUNCTION BLOCK LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/RED WIRE PPL/YEL WIRE REAR WINDOW RELAY REAR WINDOW WASHER RELAY REAR WIPER MOTOR (CENTER OF LIFTGATE) RED WIRE RELAY BOX (ENGINE ROOM) VIO WIRE WASHER MOTOR WHT WIRE WINDSHIELD WASHER RELAY WINDSHIELD WIPER MOTOR YEL WIRE
