Mitsubishi Outlander IV (2021-2024) swirl control valve actuator Wiring diagram

This page shows the only wiring diagram for the component.swirl control valve actuator, which is found in the car Mitsubishi Outlander IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram swirl control valve actuator (1 of 1)

Wiring diagram swirl control valve actuator for Mitsubishi Outlander IV (2021-2024)

Get access

A-37 B-11 BLK WIRE BLU WIRE BRN WIRE EGR VOLUME CONTROL VALVE (-) ENGINE CONTROL MODULE (LEFT REAR CORNER OF ENGINE COMPT) EVAPORATIVE EMISSION PURGE SOLENOID GRN WIRE GRY WIRE J/C 4 (B-14) (ABOVE TRANSMISSION) LT BLU WIRE LT GRN WIRE LT GRN/GRN WIRE PNK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/LT GRN WIRE PPL/PNK WIRE PPL/WHT WIRE RED WIRE SWIRL CONTROL VALVE ACTUATOR VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Wiring diagram engine performance 2.5l (3 of 8) -> SWIRL CONTROL VALVE ACTUATOR
