Mitsubishi Outlander IV (2021-2024) right vanity mirror light Wiring diagrams

This page contains all the electrical diagrams for the component. right vanity mirror light, in which he is found in the car Mitsubishi Outlander IV (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram right vanity mirror light (1 of 2)

Wiring diagram right vanity mirror light for Mitsubishi Outlander IV (2021-2024)

Get access

BLK WIRE BLU WIRE BLU/WHT WIRE E-04 E-06 E-13 E-14 GRN WIRE GRN/WHT WIRE INSTRUMENT ILLUMINATION CIRCUIT J/C 35 (E-02) J/C 36 (E-15) LEFT SUN VISOR (VANITY MIRROR LAMP SWITCH) LEFT VANITY MIRROR LIGHT MAP LAMP ASSEMBLY PNK WIRE RED WIRE RIGHT SUN VISOR (VANITY MIRROR LAMP SWITCH) RIGHT VANITY MIRROR LIGHT ROOM LAMP YEL/BLK WIRE

Go to component: -> Courtesy lamps circuit (2 of 2) -> RIGHT VANITY MIRROR LIGHT

Wiring diagram right vanity mirror light (2 of 2)

Wiring diagram right vanity mirror light for Mitsubishi Outlander IV (2021-2024)

Get access

A-09 A-36 A-42 A-45 A-51 A-71 ADAS CONTROL UNIT BACK DOOR OPENER SWITCH ASSEMBLY BLK WIRE C-78 D-04 D-37 D-79 DISTANCE SENSOR E-04 E-06 E-13 E-14 ELECTRICAL PARKING BRAKE ACTUATOR EPS-ECU G-18 GRN WIRE GRN/WHT WIRE GRY WIRE HEADLIGHT WASHER MOTOR HORN (LOW) INSIDE REAR VIEW MIRROR ASSEMBLY IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) J/C 36 (E-15) LANE CAMERA UNIT LEFT FRONT COMBINATION LIGHT LEFT FRONT FOG LIGHT LEFT FRONT SEAT HEATER LEFT HEADLIGHT ASSEMBLY LEFT VANITY MIRROR LIGHT MAP LAMP ASSEMBLY PPL/BRN WIRE PTC HEATER REAR WINDOW DEFOGGER RIGHT VANITY MIRROR LIGHT ROOM LAMP SUNROOF MOTOR ASSEMBLY, SUNROOF SWITCH WASHER MOTOR

Go to component: -> Ground distribution circuit (5 of 5) -> RIGHT VANITY MIRROR LIGHT
