Mitsubishi Outlander IV (2021-2024) right rear inner sonar sensor Wiring diagram
This page shows the only wiring diagram for the component.right rear inner sonar sensor, which is found in the car Mitsubishi Outlander IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear inner sonar sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
D-01
D-106
D-107
D-62
D-90
GRN WIRE
GRY WIRE
J/C 24 (D-59)
J/C 25 (D-66) (RIGHT "D" PILLAR)
J/C 26 (D-67)
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
RED WIRE
RIGHT FRONT INNER SONAR SENSOR
RIGHT FRONT OUTER SONAR SENSOR
RIGHT FRONT SIDE SONAR SENSOR
RIGHT REAR INNER SONAR SENSOR
RIGHT REAR OUTER SONAR SENSOR
RIGHT SIDE REAR SONAR SENSOR
SONAR CONTROL UNIT
TAN WIRE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Rear sonar circuit (2 of 2) -> RIGHT REAR INNER SONAR SENSOR
