Mitsubishi Outlander IV (2021-2024) pressure sensor roll switch Wiring diagram
This page shows the only wiring diagram for the component.pressure sensor roll switch, which is found in the car Mitsubishi Outlander IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pressure sensor roll switch (1 of 1)
A-78
ANTENNA
BCM (BODY CONTROL MODULE)
BLK WIRE
C-04
C-12
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUIT
D-07
ETACS-ECU
FUSE 30
FUSE 6
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
PPL/BLU WIRE
PPL/BRN WIRE
PPL/RED WIRE
PPL/VIO WIRE
PRESSURE SENSOR ROLL SWITCH
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
TPMS TRANSMITTER
Go to component: -> Tire pressure monitoring circuit -> PRESSURE SENSOR ROLL SWITCH
