Mitsubishi Outlander IV (2021-2024) magnetic clutch Wiring diagram
This page shows the only wiring diagram for the component.magnetic clutch, which is found in the car Mitsubishi Outlander IV (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram magnetic clutch (1 of 1)
A-43
A-45
A-66
A/C COMPRESSOR CLUTCH ASSEMBLY
A/C CONTROLLER ASSEMBLY
B-04
B-05
B-62
B-63
BATTERY TERMINAL W/ FUSIBLE LINK
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
C-13
C-61
C-79
COMPUTER DATA LINES SYSTEM
ELECTRICAL CONTROL VALVE
ETACS-ECU
FUSE 40
FUSIBLE LINK E
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
IGNITION RELAY
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
J/C 6 (B-16)
LT BLU WIRE
MAGNETIC CLUTCH
NCA WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL/BLU WIRE
PPL/GRN WIRE
PPL/PNK WIRE
RADIATOR FAN MOTOR
RADIATOR FAN RELAY
RED WIRE
SEATS SYSTEM
SMART FET
SUNLOAD SENSOR (TOP CENTER OF DASH)
TAN WIRE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Automatic a/c circuit (1 of 3) -> MAGNETIC CLUTCH
